Product Details

The Control Network uses Foxboro® qualified Ethernet equipment allowing you to configure your system to
meet your functional, performance, and plant requirements. The switches allow you to interconnect system
components (controllers, workstations, servers) effectively and to minimize the quantities and lengths of
interconnectivity cabling.
OVERVIEW
The control network equipment described in this
document has been tested and qualified for use with
The Foxboro DCS.
The qualified Ethernet switches offered are listed in
Table 1. The qualified Media Converter offered is
listed in Table 2.
FEATURES
 System scalability by interconnecting Ethernet
switches, each having 8-ports or more in various
increments
 Modular uplinks to high-speed backbones using:
• 1000Base-T
• 1000Base-SX
• 1000Base-LX
• 1000Base-LX/LH
PSS 31H-7NWEQUIP
Page 2
• 1000Base-BX
• 1000Base-TX
• 1000Base-ZX standards
 System Management software for monitoring the
health of the control system and managing the
equipment within the system
 Configuration tasks through a local console port
(CLI), and monitoring through any SNMP/RMON
based management application
 Ethernet switches and converters are European
Union (EU) Low Voltage and EMC directives
safety certified (“CE” logo marked on the product)
The 24-Port Copper managed switch (P0973JM)
provides 24 100Base-TX ports with RJ-45
connectors, two fixed 10/100/1000 Ethernet ports
and two 1000Base-X uplink (ISL) Gigabit (SFP) ports.
The two 1000Base-X uplink (ISL) Gigabit (SFP) ports
can be populated with the MGBIC uplink (ISL)
connector modules listed in Table 3.
The switch allows high performance, full-featured
layer-2 Ethernet switching in small to medium-sized
network applications, as well as high performance
direct end-station connectivity.
FEATURES
The 24-Port Copper managed switch features:
 24 ports of 100Base-TX (RJ-45)
 Two fixed RJ-45 10/100/1000 ports, configurable
for 100Base-Tx or 1000Base-TX for devices or
1000Base-TX for (ISL) uplink ports
 Two 1000Base-X uplink Gigabit (SFP) ports
 Full-duplex operation
 Supports VLAN configurations
 Configuration tasks through a local console port,
and monitoring through any SNMP/RMON based
management application.
 Port mirroring technology and diagnostics that
allow local network traffic to be redirected to an
external probe for detailed analysis
 When installed with the optional redundant power
supply, there is no single point of failure due to
power disruptions.
NOTE
Two separate branch circuits are required for
redundant power.
 Shelf, desk, or 19-inch rack mounting.
OPTIONAL REDUNDANT POWER SUPPLY
Refer to “P0973JX REDUNDANT POWER SUPPLY”
on page 19.

RELATED PRODUCTS
