ABB 1SBP260171R1001 CP502 Control Panel

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Control Panel (CP502)

Brand：ABB

Additional Information

Catalog Description:CP502 Control Panel, CP500soft needed

Long Description:Control Panel 3 programmable + 8 function Keys LCD text diplay 2 line 20 Characteres

ABB Type Designation:CP502

Ambient Air Temperature:Operation 0 ... +50 °C，Storage -20 ... +70 °C

Battery Information:Weight 0.01 kg

Battery Type:Portable

CN8:84716070

CSA Certificate:NRAG7.E224886

Character Height:5.55 mm

Communication:Depend on Driver

Communication Interface:no

Communication Speed:9.6 ... 57.6 kBd

Country of Origin:Sweden (SE)

Customs Tariff Number:84716070

Data Sheet, Technical Information:1SBC159001M6501

Declaration of Conformity - CE:1SBD240563C1000

Degree of Protection:IP65

Display Type:STN Text

Environmental Information:1SBD240171E1000

Fieldbus Interface Type:Modbus RTUAC500_ModbusASCIIothers (contact us)

Fuse Size:5 x 20_MMTx

Fuse Type:800 mAT

GSD-file for PROFIBUS Communication:No

Gross Weight:0.5 kg

Instructions and Manuals:1SBC159002M0202

Invoice Description:CP502 Control Panel, CP500soft needed

LR Certificate:LRS_0620036

Made To Order:No

Memory Size:64 kB

Memory Size User Data:64 kB

Memory Size User Program:64 kB

Memory Type User Data:64 kilobyte non-volatile RAM

Memory Type User Program:64 KB Flash EPROM

Minimum Order Quantity:1 piece

Mounting Type:Front face

Mounting on DIN Rail:No

Number of Characters Per Line:20

Number of Display Lines:2

Number of Function Keys:11

Number of LEDs:0

Operating Mode:no

Order Multiple:1 piece

Power Consumption (@Pcons):3.6 V·A

Power Supply:24 V DC

Product Depth:46.5 mm

Product Main Type:CP502

Product Name:Control Panel

Product Net Height:100 mm

Product Net Length:29 mm

Product Net Weight:0.37 kg

Product Net Width:142 mm

Product Type:PLC-CP500

Profibus:No

Programming Software:CP500 Soft

Quote Only:No

Real-time Clock:Yes

Release Type:V1.02

Screen Color:LCD with backlight

Screen Size:2.8 in

Screen Type:STN Text

Security:password protection with 8 user levels

Selling Unit of Measure:piece

Serial Port 1 Type:PR,MODBUS,ASCII,others

Serial Port 2 Type:PR,MODBUS,ASCII,others

Service Life:50000 hour

Short Description:Control Panel 3+8 function Keys LCD text diplay

Short-Circuit Protective Devices:gG Type Fuses Integrated

Software Function:recipe management

Stocked At (Warehouses):Central Stock Europe

Central Stock US，US Drive Services

Supply Voltage:20 ... 30 V DC

UL Certificate:NRAG.E224886

USB Port 1 Type:no

USB Port 2 Type:no

WEEE B2C / B2B:Business To Business

WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)
