Item NO.:
GJR5252300R0101Lead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPSIf you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！
Product Description:
Analog I/O Module (07AC91)
Brand：ABB
General Information
Extended Product Type:07AC91Product ID:GJR5252300R0101
ABB Type Designation:07AC91
EAN:4013614267666
Catalog Description:07AC91:AC31,Analog I/O module
Long Description:07AC91:AC31,Analog I/O module 8AC,24VDC,AC:U/I,12bit+Sign,1-wire
Additional Information
ABB Type Designation:07AC91
ABS Certificate:1SAA960000-0102
Ambient Air Temperature:Operation 0 ... +55 °C
Storage -25 ... +75 °C
Analog Inputs:2 modes selectable: 8AI/8AO (12 bit) or 16 channels by pair selectable as AI or AO (8 bit) with -10 ... +10V, 0 ... 20mA, 4 … 20mA
Analog Outputs:2 modes selectable: 8AI/8AO (12 bit) or 16 channels by pair selectable as AI or AO (8 bit) with -10 ... +10V, 0 ... 20mA, 4 … 20mA
CN8:85389091
CS31-Bus:1
CSA Certificate:1SAA960000-1102
Cable Cross-Section:0.08 ... 1.5 mm²
Core Credit:0.00
Country of Origin:Germany (DE)；Spain (ES)；United States (US)
Customs Tariff Number:85389091
DNV Certificate:1SAA960000-0304
Data Sheet, Technical Information:2CDC122004D0201
Declaration of Conformity - CE:1SAD938505-0047
Degree of Protection:IP20
EAN:4013614267666
Environmental Information:1SAA960001-2401
Fieldbus Interface Type:CS31 Slave
GL Certificate:1SAA960000-0401
Gross Weight:0.81 kg
I/O Option:Bus module with Onboard IO - 16AC
Instructions and Manuals:2CDC120059M0202
Invoice Description:07AC91:AC31,Analog I/O module
LR Certificate:1SAA960000-0502
Made To Order:No
Maximum Operating Altitude Permissible:2000 m
Minimum Order Quantity:1 piece
Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Number of Analog Configurable I/Os:16
Order Multiple:1 piece
Part Type:New
Primary Voltage:24 V
Product Depth:85 mm
Product Main Type:07AC91
Product Name:Distributed Automation I/O
Product Net Height:140 mm
Product Net Length:85 mm
Product Net Weight:0.81 kg
Product Net Width:120 mm
Product Type:PLC-AC31-90
Quote Only:No
RINA Certificate:1SAA960000-0802
RMRS Certificate:1SAA960000-0702
RoHS Information:1SAA960005-4401
RoHS Status:No declaration needed
Selling Unit of Measure:piece
Serial Port 1 Type:RS-485, CS31
Short Description:8AC,24VDC,AC:U/I,12bit+Sign,1-wire
Special Functions:Thermocouple inputs
Stocked At (Warehouses):SEMAC001EXPU
SGRDC002EXPU
SGIND002EXPU
AUABB024EXPU
Supply Voltage:24 V DC
Terminal Type:Screw Terminals, Pluggable
UL Certificate:1SAA960000-1602
WEEE B2C / B2B:Business To Business
WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)
