ABB GJR5253100R0270 07KT98-ETH Basic Module Ethernet

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Basic Module Ethernet (07KT98-ETH)

Brand: ABB

Additional Information

Extended Product Type:07KT98-ETH

Product ID:GJR5253100R0270

ABB Type Designation:07KT98-ETH

EAN:4013614354038

Catalog Description:07KT98 Basic Module Ethernet AC31

Ambient Air Temperature:Operation 0 ... +55 °C；Storage -25 ... +75 °C

Analog Inputs:8 channels, 0 ... +5V, -5 ... +5V, 10 bit +sign, 0 ... +10V, -10 ... +10V, 11 bit+sign, 0 ... 20mA, 4 ... 20mA, PT100 (2 or 3 wire), 12 bit, bipolar, the analog inputs are also usable as digital inputs

Analog Outputs:4 channels, -10 ... +10V, 11 bit+sign, 0 ... 20mA, 12 bit

CS31-Bus:1

Country of Origin:Germany (DE)

Customs Tariff Number:85371091

Data Sheet, Technical Information:2CDC121009D0202

Fieldbus Interface Type:Ethernet TCP/IP

Gross Volume:5.775 dm³

Gross Weight:1.62 kg

Invoice Description:07KT98 Basic Module Ethernet AC31

Maximum Number of Analog I/Os:232 AI, 224 AO

Maximum Number of Digital I/Os:1040

Memory Size User Data:1000 kB

Memory Size User Program:1000 kB

Memory Type User Data:Flash EPROM

Memory Type User Program:Flash EPROM, non-volatile RAM, SMC

Minimum Order Quantity:1 piece

Number of Analog Configurable I/Os:0

Number of Digital Configurable I/Os:8

Number of Digital Inputs DC 24V:24

Number of Digital Outputs DC 24V:16

Number of Hardware Counters:2

Object Classification Code:K

Order Multiple:1 piece

Output Current:0.5 A

Output Voltage (Uout):24 V DC

Package Level 1 Gross Weight:1.1 kg

Package Level 1 Units:1 case

Parallel Extension:1

Part Type:New

Primary Voltage:24 V

Product Depth:85 mm

Product Main Type:07KT98

Product Name:07KT98 Basic Module Ethernet AC31

Product Net Weight:1.62 kg

Product Type:Spare_Parts

Programming Software:AC1131

RoHS Status:No declaration needed

Selling Unit of Measure:piece

Serial Port 1 Type:RS232 / Programing, Modbus Master or slave

Serial Port 2 Type:RS232 / Modbus Master or slave, ASCII

Short Description:07KT98-ETH:AC31,Prog.Logic Controller

Speed for 1000 instructions (65% Logic, 35% Word):0.07 ms

Stocked At (Warehouses):Central Stock Europe

DEAPREXPU

Terminal Type:Screw Terminals, Pluggable

UL Certificate:1SAA960000-1601

WEEE Category:Product Not in WEEE Scope
