ABB PM554-T-ETH 1TNE968900R0110 Ethernet Interfaces

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Ethernet Interfaces (PM554-T-ETH)

Brand：ABB

Additional Information

ABB Type Designation:PM554-T-ETH

ABS Certificate:1SAA960003-0102

Ambient Air Temperature:Operation 0 ... +60 °C；Storage -40 ... +70 °C

Communication:Serial and Ethernet interfaces for communication and programming

Communication Interface:Serial/Ethernet

Country of Origin:Taiwan, Province Of China (TW)

Customs Tariff Number:85371091

Fieldbus Interface Type:Ethernet TCP/IP

Gross Weight:0.36 kg

I/O Option:PLC with Onboard IO - 8DI / 6DO-T

Invoice Description:PM554-T-ETH:AC500,Prog.Logic Controller 128kB,8DI/6DO-T,1xETH,1xRS485 2xOption Slots,24VDC

Maximum Hardware Counter Input Frequency:30 kHz

Maximum Number of Analog I/Os:64 AI or 64 AO or mixed up to 64 analog channels local with max. 7 extension modules

Maximum Number of Digital I/Os:256 DI or 256 DO or mixed up to 256 digital channels local with max. 7 extension modules

Maximum Operating Altitude Permissible:2000 m

Memory Size User Data:10 kB

Memory Size User Program:128 kB

Memory Type User Data:Flash EPROM

Memory Type User Program:Flash EPROM, SD Card

Minimum Order Quantity:1 piece

Mounting Position:Horizontal, Vertical possible with derating

Mounting Type:DIN rail and panel mounting

Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715

Number of Digital Inputs DC 24V:8

Number of Digital Outputs DC 24V:6

Number of Hardware Counters:2

Output Current:0.5 A

Output Voltage (Uout):24 V

Primary Voltage:24 V

Product Main Type:PM554

Product Name:Distributed Automation PLCs

Product Net Height:74 mm

Product Net Length:135 mm

Product Net Weight:0.3 kg

Product Net Width:82 mm

Product Type:PLC-AC500-eCo

Programming Software:AC500 Control Builder PS501-PROG

RoHS Status:Following EU Directive 2002/95/EC August 18, 2005 and amendment

Secondary Current:0.2 A

Selling Unit of Measure:piece

Serial Port 1 Type:RS485 non isolated, Programing, Modbus Master or slave, ASCII, CS31 Master

Serial Port 2 Type:Optional RS485 non isolated, Programing, Modbus Master or slave, ASCII

Short Description:PM554-T-ETH:AC500,Prog.Logic Controller

Supply Voltage:24 V

Terminal Type:Screw Terminals

UL Certificate:1SAA960000-1609

cUL Certificate:1SAA960000-1709
