Item NO.:
DIO248Lead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!
Product Description:
Digital Input/Output Module (DIO248)
Brand:Bachmann
Features
• 16/32/48/64 or 80 digital channels
• 16 channels can be configured as input or output
• Configurable interrupt inputs
• Configurable 32 bit counter
• Mode: event counter, incremental encoder,gate measurement, cycle time or frequency measurement
• Configurable input filter
• PWM output mode for e.g. valve economy mode
• Status display for each channel via LED
• Supply voltage 18 to 34 VDC
• Supply voltage protected against reverse polarity
• Cost effective and space saving
Specifications
Quantity:16 to 32
Input voltage range (H):15 to 34 VDC
Input voltage range (L):0 to 5 VDC
Input delay (normally):Standard: 600 µs,Settable 10 µs to 270 ms
Internal resistance:8 kOhm
Status indication (LED):Green
Interrupt inputs:8, configurable as counter inputs or interrupt inputs
Quantity:up to 4
Resolution:32 Bit
Operating mode:Event counter, incremental encoder, gate measurement, cycle time or frequency measurement
Encoder types:Incremental encoder with A and B channel and one-channel pulse encoder
Input signal:A, B, Initator (interrupt inputs configurable)
Signal evaluation:1 / 2 / 4-fold edge evaluation or pulse direction mode
Max. input frequency:One-channel: 50 kHz,Dual-channel (A/B): 20 kHz
Output voltage range:18 to 34 VDC
Output current per channel (max.):0.5 A
Total current (max.):16 A
Switching frequency(max., ohmic load):1 kHz
Inductive breaking capacity:1,15 H
About Us
We mainly manage PLC module, DCS module, CPU module, IO module, DO module, AI module, DI module, network communication module.Ethernet module, motion control module, analog input module, analog output module, digital input module, digital output.Modules, Redundancy Modules, Power Modules, Relay Output Modules, Relay Input Modules, Processor Modules.
Packaging & Delivery
Packaging Details:original packing factory sealed
Delivery Detail:Shipped in 3-5 days after payment
Shipping Detail
1) For the in stock items, we will send the order out within 3 days after receive the payment.
2) We can shipping all over the world via DHL,UPS,Fedex and EMS. The packaging is very strong. If you have any special needs, please notify me.
3) You are expected to receive the item about 7 days after we send out.
SUPPORT FROM US
1.100% New Original Factory Sealed
2.Best price
3.Fast Delivery
4.Large in stock
If you find other suppliers offer cheaper prices for the same product, we are also willing to provide you with reference to their priceand give you further discounts.
We’ll choose the best and cheapest transport company.
We’ll track the goods time by time until they arrive at client's hand
