Item NO.:
IC694ALG223Lead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！
Product Description:
16–Channel Analog Current Inputmodule (IC694ALG223)
Brand：General Electric
Specifications
Number of Channels：1 to 16 selectable; single-ended
Input Current Ranges：0 to 20 mA, 4 to 20 mA and 4 to 20 mA Enhanced (selectable per channel)
Calibration Factory calibrated to:
4 µA per count on 4 to 20 mA range
5 µA per count on 0 to 20 mA and 4 to 20 mA Enhanced range
Update Rate：13 milliseconds (all 16 channels)
Resolution at 4–20 mA：4 µA (4 µA/bit)
Resolution at 0–20 mA：5 µA (5 µA/bit)
Resolution at 4–20 mA Enhanced：5 µA (5 µA/bit)
Absolute Accuracy *：+/-0.25% of full scale @ 25°C (77°F): +/- 0.5% of full scale over specified operating temperature range
Linearity：< 1 LSB from 4 to 20 mA (4 to 20 mA range)
< 1 LSB from 100 µA to 20 mA (0 to 20 mA and 4 to 20 mA Enhanced ranges)
Isolation, Field to Backplane(optical) and to frame ground：250 VAC continuous; 1500 VAC for 1 minute
Common Mode Voltage：0 volts (single-ended channels)
Cross–Channel Rejection：> 80dB from DC to 1kHz
Input Impedance：250 Ohms
Input Low Pass Filter Response：19 Hz
External Supply Voltage Range：20 to 30 VDC
Internal Power Consumption：120 mA from the +5 VDC bus on the backplane
65 mA from 24 VDC external user power supply (in addition to current loop currents)
About Us
We mainly manage PLC module, DCS module, CPU module, IO module, DO module, AI module, DI module, network communication module.Ethernet module, motion control module, analog input module, analog output module, digital input module, digital output.Modules, Redundancy Modules, Power Modules, Relay Output Modules, Relay Input Modules, Processor Modules.
Packaging & Delivery
Packaging Details:original packing factory sealed
Delivery Detail:Shipped in 3-5 days after payment
Shipping Detail
1) For the in stock items, we will send the order out within 3 days after receive the payment.
2) We can shipping all over the world via DHL,UPS,Fedex and EMS. The packaging is very strong. If you have any special needs, please notify me.
3) You are expected to receive the item about 7 days after we send out.
SUPPORT FROM US
1.100% New Original Factory Sealed
2.Best price
3.Fast Delivery
4.Large in stock
If you find other suppliers offer cheaper prices for the same product, we are also willing to provide you with reference to their priceand give you further discounts.
We’ll choose the best and cheapest transport company.
We’ll track the goods time by time until they arrive at client's hand
