Product Description:
Analog Current/Voltage Input/Output Module (IC694ALG442)
Brand：GE
Description
● The GE Fanuc IC694ALG442 is an Analog Combination Current/Voltage Input/Output Module for Rx3i PacSystems. This module provides four distinct input channels and two single-ended output channels. Each channel can be configured using Machine Edition software in any of the following ranges: (0 to +10) unipolar, (-10 to +10 volts) bipolar, 0 to 20 mA, or 4 to 20 mA. The 0 to +10 unipolar range is the default setting for the system and will be automatic upon installation unless altered. In a higher mode, the input channels can be configured for a 4 to 20 mA range.
● This IC694ALG442 module must be attached to a 24 VDC power from an outside source for proper use. If used with the RX3i Universal Backplane, the external source can be attached through the TB1 connector located on the left hand side of the backplane. Another option is available through a direct connection on the module’s terminal block. If using the backplane, the external source must be connected to the terminal block. Resolution per bit is based on the configured input or the output range. If the current source is reversed into input, or if it is below the low end of the current range, the module inputs a data word equivalent to the low end of the range. Resolution of the translated signal is 12 binary bits from the A/D converter in the %AI. Each channel is capable of 15 to 16 bit converting.
Technical Specifications
No. of channels：4 In/2 Out
Voltage Range：0 to +10 V, -10 to +10 V
Current Range：0-20 mA, 4-20 mA
Update Rate：8 msec In/ 4 msec Out
Output Load：5 mA max
Power Consumption：95 mA @ +5VDC, 129 mA @ +24VDC Isolated
