HP 44702B 13-Bit High Speed Voltmeter

13-Bit High Speed Voltmeter
  • Item NO.:

    44702B
  • Lead Time:

    1-2days
  • Product Orgin:

    USA
  • Shipping Port:

    CHINA
  • Payment:

    T/T 、PayPal、Western Union
  • goods stock:

    3
  • Warranty :

    one year
  • Shipping Detail:

    Fedex and UPS
  • Product Details

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!

Product Description:

13-Bit High Speed Voltmeter (44702B)

Brand:HP

Product Description

- The HP 44702B high-speed voltmeter with 64K buffer is a plug-in accessory for the 3852A data acquisition and control unit.

- The voltmeter has an on-board buffer to store readings.

- The voltmeter resolution is 12 bits plus a sign bit. The volts and ohms ranges can be selected automatically or manually.

● DC voltage

     ◇ Ranges: 40 mV, 320 mV, 2.56 V, 10.24 V

     ◇ Accuracy: 0.05%

     ◇ Resolution: 12 bits plus a sign bit

     ◇ Reading rate: 100000 readings/s with auto-ranging. Signal channel must change no more than 600 V/s during auto-ranging

● Resistance functions

    ◇ 10 kΩ (1 mA current source used): Ranges 40 Ω, 320 Ω, 2.56 kΩ, 10.24 kΩ; Accuracy 0.07%

    ◇ 100 kΩ (100 µA current source used): Ranges 400 Ω, 3.2 kΩ, 25.6 kΩ, 102.4 kΩ; Accuracy 0.07%

    ◇ 1 MΩ (10 µA current source used): Ranges 4 kΩ, 32 kΩ, 256 kΩ, 10.24 MΩ: Accuracy 0.07%

● Resistance reading rate: 100000 readings/s with auto-ranging. Signal channel must change no more than 600 V/s during auto-ranging

● Pacer

    ◇ Programmable intervals: 10 µs to 17 minutes with 0.25 µs resolution

    ◇ Pulse widths: 0.5 µs nominally (low true)

● Noise rejection

    ◇ 40 mV: 90 dB ECMR

    ◇ 320 mV: 80 dB ECMR

    ◇ 2.56 V: 70 dB ECMR

    ◇ 10.24 V: 70 dB ECMR

● Maximum input voltage: All inputs are protected to 16 Vpeak. Input impedance decreases above 12 V

● Bandwidth

    ◇ 40 mV range: 10 kHz (0.1% flatness), 45 kHz (1.0% flatness), 250 kHz (-3 dB bandwidth)

    ◇ 320 mV to 10.24 V range: 15 kHz (0.1% flatness), 55 kHz (1.0% flatness), 400 kHz (-3 dB bandwidth)
