ICS Triplex T8451 Digital Output Module

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Digital Output Module (T8451)

Brand：ICS TRIPLEX

Additional Information

Product No : T8451

Product type : TrustedTM Module

System Supply Voltage Range : 20 to 32Vdc

Circuit Type : Fault tolerant, fully triplicated with optional line monitoring

Number of Outputs : 40 Channels

Independent Power Groups : 5 each of 8 outputs

Operational Output/Field Voltage Range : 18 to 32V dc

▷ Output Voltage

 ● Measurement Range : 0 to 32V dc

 ● Maximum Withstanding : -1 to 40V dc

 ● Output Current Rating (Continuous) : 2A per channel limited to 8A per power group

▷ Maximum capacitance : Pre release 3.5: 30-55uF

 ● Flashing/pulsing current loads : Release 3.5 is recommended

 ● Minimum On State Load Current : 50mA

 ● Output Off State Resistance (effective leakage) :

33O

 ● Output On State resistance : 0.6O

 ● Output Short Circuit Protection : Electronic (latching)

 ● Channel to Channel Crosstalk : >-40dB

Release 3.5: at least 2800uF at 2A

▷ Power Consumption

 ● Field Supply (1A per channel) : 24W

 ● System Supply (24V) : 24W

▷ Field Common Isolation

 ● Sustained Working : ±250V dc

 ● Maximum Withstanding : ±2.5kV dc

 ● Output Turn-on/off Delay : 0.5ms

 ● Sample Update Time : 0.5ms

 ● Sequence of Events

 ● Event Resolution : 1ms

 ● Self-Test Interval : 2 minutes

 ● Intrinsic Safety : External barrier

 ● Output Short Circuit Protection : Automatic

 ● Operating Temperature : -5°C to 60°C (23°F to 140°F)

 ● Non-operating Temperature : -25°C to 70°C (-13°F to 158°F)

 ● Temperature change : 0.5ºC/min

 ● Operating Humidity : 5 – 95% RH non-condensing

Dimensions (LxWxH) : 30cm x 3cm x 24.1cm

Weight : 1.13 Kg

Shipping Weight : 3 Kg
