MITSUBISHI MR-J2S-200A Servo Amplifier

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Servo Amplifier (MR-J2S-200A)

Brand：Mitsubishi Electric

Product Description

● Power Supply (Voltage/frequency): 3-phase 200-230VAC, 50/60Hz

● Power Supply (Permissible voltage fluctuation): 3-phase 170-253VAC

● Power Supply (Permissible frequency fluctuation): ±5%

● Control System: Sinusoidal PWM control/current control system

● Dynamic brake: Built-in

● Speed frequency response: 550 Hz or more

● Protective functions: Overcurrent shutdown, regeneration overvoltage shutdown, overload shutdown (electronic thermal), servomotor overheat protection, encoder fault protection, regeneration fault protection, undervoltage/sudden power outage protection,overspeed protection, excess error protection

● Maximum input pulse frequency (Position control mode): 500 kpps- when using differential receiver, 200 kpps- when using open collector

● Positioning feedback pulse (Position control mode): Resolution per encoder/servo motor rotation (131072 pulse/revolution)

● Positioning complete width setting (Position control mode): 0 - ±10VDC

● Excess error (Position control mode): ±10 rotations

● Torque limit input (Position control mode): Set by parameters or external analog input (0-±10VDC / maximum torque)

● Speed control range (Speed control mode): Analog speed command 1:2000, internal speed command 1:5000

● Analog speed command input (Speed control mode): 0-±10VDC / rated speed

● Speed fluctuation rate (Speed control mode): ±0.01% max.(load fluctuation 0-100%), 0% (power fluctuation ±10%), ±0.2% max. (ambient temperature 25°C ± 10°C), when using external analog speed command

● Torque limit (Speed control mode): Set by parameters or external analog input (0-±10VDC / maximum torque)

● Torque command input (Torque control specifications): 0-±8VDC / maximum torque (input impedance 10 to 12kΩ)

● Speed limit (Torque control specifications): Set by parameters or external analog input (0-±10VDC, rated speed)

● Structure: Fan-cooling, open (IP00)

● Shipping Weight: 3.1 kg
