SCHNEIDER 140ACI03000 Analog Input Module

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Analog Input Module (140ACI03000)

Brand：Schneider

Additional Information

range of product：Modicon Quantum automation platform

product or component type：Analogue input module

type of filter：Single pole low pass - 3 dB at 15 Hz +/- 20 %

analogue input number：8

input type：Differential

addressing requirement：9 input words

analogue input resolution：12 bits

linear measuring range：1...5 V；4...20 mA

absolute maximum input：50 V DC；25 mA

input impedance ：250 Ohm current +/- 0.01 %；> 20 MOhm voltage

absolute accuracy error：+/- 0.05 % of full scale；+/- 0.1 % of full scale maximum

linearity error：+/- 0.04 %

accuracy drift according to temperature：+/- 0.0025 % of full scale/°C；<= 0.005 % of full scale/°C

common mode rejection：> - 72 dB 60 Hz

isolation between channels and bus：1000 V DC；3000 V DC for 60 s

isolation between channels：30 V DC

update time：5 ms

fault type：Broken wire 4...20 mA；Undervoltage range 1...5 V

local signalling：

1 LED (green)bus communication is present (Active)

1 LED (red)external fault

8 LEDs (green)channel is turned on

8 LEDs (red)channel fault

bus current requirement：240 mA

power dissipation in W：2 W

module format：Standard

net weight：0.3 kg

standards：UL 508；CSA C22.2 No 142

product certifications：FM Class 1 Division 2；CUL

resistance to electrostatic discharge：

4 kV contact conforming to IEC 801-2

8 kV on air conforming to IEC 801-2

resistance to electromagnetic fields：10 V/m 80…1000 MHz conforming to IEC 801-3

ambient air temperature for operation：0…60 °C

ambient air temperature for storage：-40…85 °C

relative humidity ：95 % without condensation

operating altitude：<= 5000 m
