SCHNEIDER 140ATI03000 Input Module

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Input Module (140ATI03000)

Brand：Schneider Electric

Additional Information

Part Number：140ATI03000

Series：Modicon Quantum

Type of filter：Single pole low pass - 3 dB at 20 Hz

Notch filter - 3 dB at 50/60 Hz

Analogue input number：8

Addressing requirement：10 input words

Analogue input type：

Thermocouple - 50...1665 °C thermocouple S

Thermocouple - 50...1665 °C thermocouple R

Thermocouple - 270...400 °C thermocouple T

Thermocouple - 270...1370 °C thermocouple K

Thermocouple - 270...1000 °C thermocouple E

Thermocouple - 210...760 °C thermocouple J

Analogue input resolution：16 bits

Input impedance：> 1 MOhm

Absolute accuracy error：

+/- 4 °C plus + 0.1 % of reading thermocouple S

+/- 4 °C plus + 0.1 % of reading thermocouple R

+/- 2 °C plus + 0.1 % of reading thermocouple T

+/- 2 °C plus + 0.1 % of reading thermocouple K

+/- 2 °C plus + 0.1 % of reading thermocouple J

+/- 2 °C plus + 0.1 % of reading thermocouple E

Linearity error：

1 °C, 0.1 °C, 1 F, 0.1 F - 50...1665 °C

1 °C, 0.1 °C, 1 F, 0.1 F - 270...400 °C

1 °C, 0.1 °C, 1 F, 0.1 F - 270...1370 °C

1 °C, 0.1 °C, 1 F, 0.1 F - 270...1000 °C

1 °C, 0.1 °C, 1 F, 0.1 F - 210...760 °C

Accuracy drift according to temperature：0.15 µV/°C + 0.0015 % of reading/°C max low level voltage

Common mode rejection：>= 120 dB 50/60 Hz

Isolation between channels and bus：2500 V DC for 60 s；1780 V AC for 60 s

Isolation between channels：220 V AC；300 V DC

Update time：1000 ms

Fault type：Overtacking scale；Broken wire

Marking：CE

Cold junction compensation：Internal 0...60 °C

Local signalling：8 LEDs red channel fault

8 LEDs green channel is turned on

1 LED red external fault

1 LED green bus communication is present (Active)

Bus current requirement：280 mA

Power dissipation in W：1.5 W
