Product Description:
Analog Mixed Current/Voltage Input Modules (140AVI03000)
Brand:Schneider
Additional Information
Part Number:140AVI03000
Series:Modicon Quantum
Weight:1lb
Type:IO Modules
Module format:Standard
Type of filter:Single pole low pass - 3 dB at 847 Hz +/- 20 %
Analogue input number:8
Input type:Differential
Addressing requirement:9 input words
Analogue input type:
Unipolar voltage 0...5 V
Unipolar voltage 0...10 V
Unipolar current 0...20 mA
Bipolar voltage +/- 5 V
Bipolar voltage +/- 10 V
Bipolar current 20 mA
Analogue input resolution:
16 bits 20 mA
16 bits 0...5 V
16 bits 0...20 mA
16 bits 0...10 V
16 bits +/- 5 V
16 bits +/- 10 V
Linear measuring range:
(Input range) x 1.024 mA
(Input range) x 1.024 V
Absolute maximum input:50 V DC;25 mA
Input impedance:
250 MOhm +/- 0.03 %
> 20 Ohm voltage
Absolute accuracy error:+/- 0.05 % of full scale maximum;+/- 0.03 %
Linearity error:+/- 0.008 %
Accuracy drift according to temperature:
<= 0.004 % of full scale /°C
+/- 0.0015 % of full scale/°C
Common mode rejection:> -80 dB 60 Hz
Isolation between channels and bus:750 V DC;500 Vrms AC for 60 s
Isolation between channels:135 Vrms AC;200 V DC
Update time:10 ms
Fault type:Overtacking scale 1...5 V;Broken wire 4...20 mA
Marking:CE
Local signalling:
8 LEDs red channel fault
8 LEDs green channel is turned on
1 LED red external fault
1 LED green bus communication is present (Active)
Bus current requirement:280 mA
Power dissipation in W:2.2 W
