Item NO.:
140DRA84000Lead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!
Product Description:
Discrete Output Module (140DRA84000)
Brand:Schneider
Additional Information
Part Number:140DRA84000
Series:Modicon Quantum
Weight:1lb
Type:Accessories
Module format:Standard
Product or component type:Relay discrete output module
Discrete output number:16
Contacts type and composition:1 NO
Contact form:Form A
Discrete output voltage:
5...30 V DC
30...150 V DC
20...250 V AC
Addressing requirement:1 output word
Minimum load:
>= 50 mA 5...30 V DC
>= 50 mA 20...250 V AC
Maximum load current:
300 mA 30...50 V DC resistive
2 A 250/30 V AC/DC resistive at 60 °C
1 A 250/30 V AC/DC tungsten
1 A 250/30 V AC/DC 1/8 hp cos phi = 0.4
Surge current:<= 10 A for 10 ms capacitive
Switching capacity in VA:500 VA resistive
Response time on input opening:
<= 20 ms at state 1 to state 0
<= 10 ms at state 0 to state 1
Mechanical durability:10000000 cycles
Electrical durability:
50000 cycles 500 mA 30...150 V DC resistive
200000 cycles 2 A 250 V AC resistive
100000 cycles 300 mA 30...150 V DC resistive
100000 cycles 30...150 V DC interposing relay
100000 cycles 2 A 30 V DC resistive
100000 cycles 100 mA 30...150 V DC L/R = 10 ms
Output overvoltage protection:Internal by varistor, 275 V
Isolation between channels:1780 Vrms AC for 1 minute
Isolation between channels and bus:
2500 V DC for 1 minute
1780 Vrms AC for 1 minute
Power dissipation:5.5 W + (0.5 x the number of points on)
Marking:CE
Local signalling:
16 LEDs green input status
1 LED red external fault detected (F)
1 LED green bus communication is present (Active)
Bus current requirement:1100 mA
