SCHNEIDER TSXP571634M Processor Module

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Processor Module (TSXP571634M)

Brand：Schneider

Additional Information

Product or component type：Unity processor

Number of racks：2 12 slots，4 4/6/8 slots

Discrete I/O processor capacity：512 I/O

Analogue I/O processor capacity：24 I/O

Integrated connection type：Ethernet TCP/IP RJ45

Serial link 2 female mini DIN RS485 19.2 kbit/s

Memory description：PCMCIA card 256 kB additional data storage

Internal RAM (with PCMCIA card) 224 kB program

Internal RAM (with PCMCIA card) 96 kB data

Internal RAM (without PCMCIA card) 96 kB program and data

Software designation：Unity Pro

Protective treatment：TC

Port Ethernet：10BASE-T/100BASE-TX

Maximum size of object areas：32 kB (elementary and derived data) unlocated internal data

64 %KWi constant words located internal data

64 %MWi internal words located internal data

64 kB (DFB and EFB function blocks) unlocated internal data

4096 %Mi located internal bits

Application structure：1 fast task

1 master task，32 event tasks

Execution time per instruction：0.19 µs Boolean without PCMCIA card

0.25 µs word or fixed-point arithmetic without PCMCIA card

0.25 µs Boolean with PCMCIA card

0.5 µs word or fixed-point arithmetic with PCMCIA card

1.75...2.6 µs floating points without PCMCIA card

1.75...2.6 µs floating points with PCMCIA card

Number of instructions per ms：2.1 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card

3.1 Kinst/ms 100 % Boolean with PCMCIA card

3.71 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card

4.76 Kinst/ms 100 % Boolean without PCMCIA card

System overhead：0.3 ms fast task，1 ms master task

Marking：CE

Local signalling：1 LED green processor running (RUN)

1 LED red processor or system fault (ERR)

1 LED red I/O module or configuration fault (I/O)

1 LED yellow activity on TER or AUX terminal port (TER)

1 LED green Ethernet TCP/IP port ready (RUN)

1 LED red Ethernet TCP/IP port fault (ERR)

1 LED red collision detection (COL)

1 LED yellow Ethernet link diagnostics (STS)

1 LED yellow transmission activity (TX)

1 LED yellow reception activity (RX)

Current consumption：1650 mA 5 V DC
