SCHNEIDER TSXP57303AM Processor

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Processor (TSXP57303AM)

Brand：Schneider Electric

Additional Information

Part Number：TSXP57303AM

Series：Modicon Premium

Product or component type：Double-format PL7 processor

Number of racks：8 12 slots；16 4/6/8 slots

Discrete I/O processor capacity：1024 I/O

Analogue I/O processor capacity：128 I/O

Integrated connection type：Serial link 2 female mini DIN 19.2/115 kbit/s

Communication module：1 CANopen bus module

processor：2 fieldbus modules (1 if CANopen used)

3 network modules

8 AS-Interface bus modules

Memory description：

PCMCIA card 384 Kwords program

PCMCIA card 2688 Kwords additional data storage

Internal RAM (with PCMCIA card) 80 Kwords data

Internal RAM (without PCMCIA card) 64 Kwords

program and data

Software designation：PL7 Junior/Pro

Protective treatment：TC

Maximum size of object areas：30.5 %MWi internal words located internal data

32 %KWi constant words located internal data

16384 %Mi located internal bits

Application structure：1 fast task

1 master task；64 event tasks

Execution time per instruction：

0.12 µs Boolean without PCMCIA card

0.17 µs word or fixed-point arithmetic without PCMCIA card

0.17 µs Boolean with PCMCIA card

0.33 µs word or fixed-point arithmetic with PCMCIA card

2.5 µs floating points without PCMCIA card

2.6 µs floating points with PCMCIA card

Number of instructions per ms：3.08 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card

4.49 Kinst/ms 100 % Boolean with PCMCIA card

4.7 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card

6.57 Kinst/ms 100 % Boolean without PCMCIA card

System overhead：0.29 ms fast task；1.15 ms master task

Marking：CE

Local signalling：

1 LED green processor running (RUN)

1 LED red processor or system fault (ERR)

1 LED red I/O module or configuration fault (I/O)

1 LED yellow activity on the terminal port (TER)

Current consumption：1000 mA
