Bachmann DIO16-C Digital I/O Module

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Digital I/O Module (DIO16-C)

Brand：Bachmann

Description

• Stand-alone, compact CAN slave module

• 16 / 32 channels can be freely configured as input or output

• Digital outputs each with 1 A continuous current

• Two internally connected CAN interfaces for loop-through of the cable

• Galvanic isolation between CAN interfaces and control electronics

• Baud rate and node ID can be set via rotary switch

• Supply voltage 18 to 34 VDC

• Operating range 0 to +60°C without additional cooling

• Full wiring without additional backplanes

• Snappable on EN 50022 backplanes

Specifications

Quantity：Max. 16

Input delay：< 3.5 ms

Internal resistance：6 kΩ

Status display：Green LED

Supply voltage：18 to 34 VDC

Isolated output blocks：1-16

Nominal output current：1 A

Output current (sum/block)：Max. 12 A

Switching frequency：Max. 500 Hz

Transfer rate (Kbaud)：10 to 1000

Connection：2x 9-pin D-Sub

Module ID：1 to 254

Galvanic isolation：500 V

Terminating resistance：123 Ω, external

Voltage range：18 to 34 VDC

Current consumption(without I /O)：Normally 100 mA at 24 VDC

CAL/CANopen：DS 301 communication profile, DS 401 device profile

Operating temperature：-30 to +60°C

Rel. humidity operation：：5 to 95% without condensation

Storage temperature：-40 to +85°C

Rel. humidity storage：5 to 95% with condensation

Pollution degree：2 (without condensation; according to IEC 60664-1)
