Item NO.:
DIO32-CLead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！
Product Description:
Digital I/O Module (DIO32-C)
Brand：Bachmann
Description
• Stand-alone, compact CAN slave module
• 16 / 32 channels can be freely configured as input or output
• Digital outputs each with 1 A continuous current
• Two internally connected CAN interfaces for loop-through of the cable
• Galvanic isolation between CAN interfaces and control electronics
• Baud rate and node ID can be set via rotary switch
• Supply voltage 18 to 34 VDC
• Operating range 0 to +60°C without additional cooling
• Full wiring without additional backplanes
• Snappable on EN 50022 backplanes
Specifications
Quantity：Max. 32
Input delay：< 3.5 ms
Internal resistance：6 kΩ
Status display：Green LED
Supply voltage：18 to 34 VDC
Isolated output blocks：1-16, 17-32
Nominal output current：1 A
Output current (sum/block)：Max. 12 A
Switching frequency：Max. 500 Hz
Transfer rate (Kbaud)：10 to 1000
Connection：2x 9-pin D-Sub
Module ID：1 to 254
Galvanic isolation：500 V
Terminating resistance：123 Ω, external
Voltage range：18 to 34 VDC
Current consumption(without I /O)：Normally 100 mA at 24 VDC
CAL/CANopen：DS 301 communication profile, DS 401 device profile
Operating temperature：-30 to +60°C
Rel. humidity operation：：5 to 95% without condensation
Storage temperature：-40 to +85°C
Rel. humidity storage：5 to 95% with condensation
Pollution degree：2 (without condensation; according to IEC 60664-1)
