Item NO.:
AJ65SBTB1-32DTLead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!
Product Description:
CC-Link Remote I/O Module (AJ65SBTB1-32DT)
Brand:Mitsubishi
Additional Information
● CC-Link small type remote I / O unit (DC input / transistor output, terminal block) AJ65SBTB1-32DT
● Input specification :
● Input format : DC input (plus common type)
● Number of input points : 16 points
● Rated input voltage : DC 24 V (ripple ratio within 5%) (Allowable voltage range DC 19.2 to 26.4 V)
● Rated input current : About 7 mA
● Maximum number of simultaneous input points : 100%
● ON voltage / ON current : 14 V or more / 3.5 mA or more
● OFF voltage / OFF current : 6 V or less / 1.7 mA or less
● Input resistance : About 3.3 kΩ
● Input response time OFF → ON : 1.5 ms or less (24 VDC)
● ON → OFF : 1.5 ms or less (24 VDC)
● Input isolation method : Photocoupler isolation
● Output format : Transistor output (sink type)
● Number of output points : 16 points
● Rated load voltage : DC 24V
● Used load voltage range : DC 19.2 to 26.4 V (ripple ratio within 5%)
● Maximum load current : 0.5 A / 1 point, 3.6 A / 1 common
● Maximum inrush current : 1.0 A less than 10 ms
● Leakage current at OFF : 0.25 mA or less
● Maximum voltage drop during ON : DC 0.3 V or less (TYP.) 0.5 A, DC 0.6 V or less (MAX.) 0.5 A
● Output response time OFF → ON : 0.5ms or less
● ON → OFF : 1.5 ms or less (resistance load)
● Surge suppressor : Zener diode
● Protection function : Overload protection function, overvoltage protection function, overheat protection function
● Output section External power supply Voltage : DC 19.2 to 26.4 V (ripple ratio within 5%)
● Current : 30 mA or less (24 VDC, per common) External load current is not included
● Output isolation method : Photocoupler isolation
● Common method : 32 points 1 common (terminal trapezoid 1 wire type)
● Withstand voltage : Between DC external terminal and ground: AC 500 V for 1 minute
● Insulation resistance : DC external terminal collective to ground: 500 VDC DC insulation resistance meter 10 MΩ or more
● Protection grade : IP2X
● Station type : Remote I / O station
● Number of occupied stations : 1 station
● Unit power supply Voltage : DC 20.4 to 26.4 V (ripple ratio within 5%)
● Current : 60 mA or less (24 VDC, all points ON)
● External wiring connection method : Communication part, unit power supply part: 7 points 2 piece terminal block (M3 screw) I / O power supply part, input / output part: 34 points Direct mounting terminal block (M3 screw)
● External dimensions Height (H) : 50 mm
● Width (W) : 179 mm
● Depth (D) : 40 mm
● mass : 0.25 Kg
● Operating ambient temperature : 0 to 55 ° C
● Storage ambient temperature : -20 to 75 ° C
● Ambient operating humidity : 10 to 90% RH, non condensing
● Storage ambient humidity : 10 to 90% RH, non condensing
● Anti-vibration Meets JIS B 3502, IEC 61131-2 When there is intermittent vibration : Frequency: 5 to 8.4 Hz, One amplitude: 3.5 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 9.8 m / s 2 Sweep count: 10 times in X, Y, Z directions
● When there is continuous vibration : Frequency: 5 to 8.4 Hz, One amplitude: 1.75 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 4.9 m / s 2
● Impact resistance : Meets JIS B 3502, IEC 61131-2 (147 m / s 2 , 3 times in each of X, Y and Z directions)
● Use atmosphere : No corrosive gas
● Use elevation : 0 to 2000 m
● Installation location : In the control panel
● Over voltage category : II or less
● Pollution degree : 2 or less
● Shipping Weight : 1.3 Kg
