Product Description:
CC-Link Remote I/O Module (AJ65SBTB2N-16S)
Brand:Mitsubishi
Additional Information
● CC-Link small type remote I / O unit (triac output, terminal block) AJ65SBTB2N-16S
● Number of output points : 16 points
● Rated load voltage, frequency : AC 100 to 240 V, 50/60 Hz ± 5%
● Maximum load current : 0.6 A / 1 point, 4.8 A / 1 common
● Load voltage distortion rate : Within 5%
● Maximum load voltage : AC 264 V
● Minimum load voltage . current : AC 50 V 100 mA, AC 100 V 10 mA, AC 240 V 10 mA
● Maximum inrush current : 25 A 10 ms or less
● Leakage current at OFF : 3 mArms or less (at 200 Vrms at 60 Hz), 1.5 mArms or less (at AC 100 Vrms at 60 Hz)
● Maximum voltage drop during ON : AC 1.5 Vrms or less (at 0.6 A)
● Output response time OFF → ON : 1ms or less
● ON → OFF : 1 ms + 0.5 cycles or less
● Surge suppressor : CR absorber (0.01 μF + 47 Ω)
● Output common method : 16 points 1 common (terminal trapezoid 2 wire type)
● Output isolation method : Photocoupler isolation
● Withstand voltage : Between AC external terminal and ground: AC 2830 Vrms / 3 cycles (altitude 2000 m) Between DC external terminals and ground: AC 500 V 1 min
● Insulation resistance : AC external terminal all together and ground, DC external terminal collective to ground: 500 MV DC insulation resistance meter 10 MΩ or more
● Station type : Remote I / O station
● Number of occupied stations : 1 station
● Unit power supply Voltage : DC 20.4 to 26.4 V (ripple ratio within 5%)
● Current : 85 mA or less (24 VDC, all points ON)
● External wiring connection method : Communication part, unit power supply part: 7 points 2 piece terminal block (M3 screw) I / O power supply part, input / output part: 34 points Direct mounting terminal block (M3 screw)
● External dimensions Height (H) : 50 mm
● Width (W) : 179 mm
● Depth (D) : 40 mm
● mass : 0.35 Kg
● Operating ambient temperature : 0 to 55 ° C
● Storage ambient temperature : -20 to 75 ° C
● Ambient operating humidity : 10 to 90% RH, non condensing
● Storage ambient humidity : 10 to 90% RH, non condensing
● Anti-vibration Meets JIS B 3502, IEC 61131-2 When there is intermittent vibration : Frequency: 5 to 8.4 Hz, One amplitude: 3.5 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 9.8 m / s 2 Sweep count: 10 times in X, Y, Z directions
● When there is continuous vibration : Frequency: 5 to 8.4 Hz, One amplitude: 1.75 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 4.9 m / s 2
● Impact resistance : Meets JIS B 3502, IEC 61131-2 (147 m / s 2 , 3 times in each of X, Y and Z directions)
● Use atmosphere : No corrosive gas
● Use elevation : 0 to 2000 m
● Installation location : In the control panel
● Over voltage category : II or less
● Pollution degree : 2 or less
● Shipping Weight : 1.4 Kg
