Item NO.:
E2E-X10D1-M1J-TLead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!
Product Description:
Standard Type Proximity Sensor (E2E-X10D1-M1J-T)
Brand:Omron
Additional Information
Type:Cylinder type (with screw), Shielded
Power source:DC 2-wire models
Sensing distance:10 mm ±10%
Setting distance:0 to 8 mm
Differential distance:10% max. of sensing distance
Sensing object:Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object:Iron 30 x 30 x 1 mm
Response frequency:0.4 kHz
Power supply voltage:12 to 24 VDC ripple (p-p) 10% max.
Operating voltage range:10 to 30 VDC
Used as UL-certified Models: 12 to 24 VDC
Leakage current:0.8 mA max.
Control output (Switching capacity):3 to 100 mA
Control output (Residual voltage):5 V max. (Load current 100 mA with cable length of 2 m)
Indicator:Operation indicator (red), Operation setting indicator (green)
Protective circuit:Output short-cut protection
Surge suppressor
Ambient temperature (Operating):-25 to 70 ℃
Ambient temperature (Storage):-40 to 85 ℃
Ambient humidity (Operating):35 to 95% RH
Ambient humidity (Storage):35 to 95% RH
Temperature influence:±10% max. of sensing distance at 23 ℃ in the temperature range of -25 to 70 ℃
Voltage influence:±1% max. of sensing distance at rated voltage in the rated voltage ±15% range
Insulation resistance:Between charged parts and the case: 5 MΩ min. at 500 VDC
Dielectric strength:Between charged parts and the case: 1,000 VAC 50/60 Hz 1 min
Vibration resistance:Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h
Shock resistance:Destruction: 1000 m/s**2 10 times each in X, Y, and Z directions
