Item NO.:
E6B2-CWZ6CLead Time:
1-2daysProduct Orgin:
USAShipping Port:
CHINAPayment:
T/T 、PayPal、Western Uniongoods stock:
3Warranty :
one yearShipping Detail:
Fedex and UPS
If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us!!
Product Description:
Rotary Encoders (E6B2-CWZ6C)
Brand:Omron
Additional Information
Categorise:Incremental Shaft model
Diameter:40 mm dia.
Power supply voltage:5 to 24 VDC (-5% to +15%) Ripple (p-p) 5% max.
Current consumption:80 mA max.
Resolution:1200 P/R
Inrush current:Approx. 9 A (0.3 ms)
Output phases:A, B and Z
Output type:NPN open collector
Load power supply voltage:30 VDC max.
Sink current:35 mA max.
Residual voltage:0.4 V max. (at sink current 35 mA)
Starting positional point:Equipped
Max. response frequency:100 kHz
Phase difference on output:90±45 ° between A and B (1/4 T ± 1/8 T)
Rise and fall times of output:1 µs max. (Cable length: 2 m max., output voltage: 5 V, load resistance: 1 kΩ)
Starting torque:0.98 mN.m max.
Moment of inertia:1 x 10**-6 kg.m**2 max.
Shaft loading:Radial: 30 N;Thrust: 20 N
Max. permissible rotation:6000 r/min
Protective circuit:Output short-cut protection
Power supply reverse polarity protection
Ambient temperature:
Operating: -10 to 70 ℃ (with no icing)
Storage: -25 to 85 ℃ (with no icing)
Ambient humidity:Operating: 35 to 85% RH (with no condensation)
Storage: 35 to 85% RH (with no condensation)
Insulation resistance:Between charged parts and the case: 20 MΩ or higher (500 VDC megger)
Dielectric strength:Between charged parts and the case: 500 VAC 50/60 Hz 1 min
Vibration resistance:Destruction: 10 to 500 Hz, 2-mm or 150 m/s**2 double amplitude for 11 min 3 times each in X, Y, and Z directions
Shock resistance:Destruction: 1000 m/s**2 for 3 times each in X, Y, and Z directions
Degree of protection:IEC: IP50
Connection method:Pre-wired models (Cable length: 0.5 m)
Weight:Package: Approx. 100 g
