Product Description:
Analogue Comb Module (140AMM09000)
Brand:Schneider Electric
Additional Information
Part Number:140AMM09000
Type of filter:Single pole low pass - 3 dB at 21 Hz +/- 20 % input,circuit
I/O modularity 6 channels
Addressing requirement:2 output words,5 input words
Analogue input number:4
Analogue input type:Unipolar voltage 0...5 V 15 bits DC
Unipolar voltage 0...10 V 16 bits DC
Unipolar offset voltage 1...5 V 14 bits DC
Unipolar offset current 4...20 mA 14 bits DC
Unipolar current 0...20 mA 15 bits DC
Bipolar voltage +/- 5 V 15 bits DC
Bipolar voltage +/- 10 V 16 bits DC
Bipolar current +/- 20 mA 15 bits DC
Absolute maximum input:+/- 50 V voltage,+/- 25 mA current
Input impedance:> 250 Ohm current,> 10 MOhm voltage
Offset:+/- 0.0014 % of full scale maximum/°C 0...60 °C input circuit
Gain shift:+/- 0.002 of full scale maximum 0...60 °C input circuit
Common mode rejection:> 80 dB 50/60 Hz input circuit
Analogue output number:2
Analogue output range:4...20 mA
Analogue output resolution:12 bits
Loop voltage:7...30 V DC output circuit
<= 60 V DC with external resistance output circuit
Voltage drop:7...30 V DC 20 mA
Setting time:900 µs to +/- 0.1 % of the final value output circuit
External power requirement:7...30 V output circuit
Absolute accuracy error:+/- 0.20 % of full scale at 25 °C output circuit
+/- 0.05 % of full scale maximum at 25 °C input circuit
+/- 0.03 % at 25 °C input circuit
+/- 0.007 %/°C of full scale maximum at 0...60 °C output circuit
+/- 0.004 % of full scale at 0...60 °C output circuit
Linearity:Monotonic +/- 1 LSB output
Monotonic +/- 1 LSB input
2.4 % over range, and - 9.6 % under range current
2.4 % over and under range voltage
Update time:320 ms input circuit,15 ms output circuit
Fault type:Status byte output circuit
Overtacking scale (unipolar) input circuit
Open circuit input/output circuit
Isolation between channels:750 V DC for 1 minute,500 V AC for 1 minute
Isolation between channels and bus:750 V DC for 1 minute,500 V AC for 1 minute
Isolation between input channels and output chan-:750 V for 1 minute
nels:500 V for 1 minute
Marking:CE
Local signalling:6 LEDs red channel fault
6 LEDs green channel is turned on
1 LED red external fault
1 LED green bus communication is present (Active)
Bus current requirement:350 mA
