SCHNEIDER 140CPU65160 Unity Processor

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Unity Processor (140CPU65160)

Brand：Schneider Electric

Additional Information

Part Number：140CPU65160

Electrical connection：1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus

1 connector, connector type: RJ45 for connecting Modbus bus

1 connector, connector type: RJ45 for connecting Ethernet network

1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and

secondary PLCs (hot standby architecture)

Clock frequency：266 MHz

Number of slots 10，16，2，4，6

Number of racks：2 - local rack(s)

Number of distributed I/O station：63 station(s) - 1 rack(s) - 3 distributed network(s)

Number of remote I/O station：31 - 2 remote rack(s)

Discrete I/O number：8000 inputs, 8000 outputs - distributed - per network

31744 inputs, 31744 outputs - remote

Unlimited (26 slots max) - local

Analogue I/O number：Unlimited (26 slots max) - local

500 inputs, 500 outputs - distributed - per network

1984 inputs,1984 outputs - remote

Application specific I/O：Accurate time stamping，Counter

High-speed interrupt inputs，Serial link

Number of optional modules：6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)

Maximum number of connections Unlimited (AS-Interface) - local

6 (Profibus DP) - local

6 (Modbus Plus) - local

6 (Ethernet TCP/IP) - local

4 (AS-Interface) - remote

2 (AS-Interface) - distributed

1 (USB)，1 (Modbus) - RS232/485 Modbus/ASCII

Integrated connection type：1 Ethernet TCP/IP

1 Modbus，1 Modbus Plus，1 USB

Checks：Process control

Memory description：Internal RAM 1024 kB

Expandable 8 MB - file storage with PCMCIA card

Expandable 7168 kB - program with PCMCIA card

Switch function：Key switch memory port on/off

Application structure：4 auxiliary tasks

32 timer interrupt tasks

128 interrupt tasks

128 I/O interrupt tasks

1 periodic fast task

1 cyclic/periodic master task

Execution time per instruction：0.4...0.5 µs floating points

0.0525...0.075 µs Boolean

0.045...0.06 µs on word

0.045...0.06 µs on fixed-point arithmetic

Execution time for 1 K instruction：10.28 100 % Boolean

10.07 65 % Boolean and 35 % numerical

System overhead：1 ms - master task，0.2 ms - fast task

Bus current requirement：2760 mA

Local signalling：1 LED red for Ethernet collision

1 LED green for Ethernet activity (COM)
